CC58 Compression Coupler, Silicone Bronze – nVent ERICO

Description

Use when compression couplers are required around ground rod splices. Enable ground rods to be driven deep quickly and easily without the risk of rod separation. Manufactured of high-strength silicon bronze. Coupling is tapered, so when the rod is driven into the coupling the two parts compress to form a conductive connection.

• Threadless compression coupler for use with pointed copper-bonded ground rods
• Inside of coupler is tapered so ground rod compresses during installation to form an irreversible conductive connection
• The compression coupler is installed easily and quickly without the risk of separating the rod
• The 2 rods are connected at their ends by the compression coupler, forming a conductive connection

Wire Size8-2MaterialSilicone BronzeDimensions5/8 in Dia x 2-3/4 in LSuitable forPointed Copper Bonded Ground RodsTypeCompression Coupler
