FRN-R-25 Fuse, 25 A, 250 VAC, 125 VDC, 20, 200 kA Interrupt, Fiberglass Body, H

Description

Provides motor overload, ground fault and short-circuit protection. Helps protect motors against burnout from overloads and single phasing on three phase systems. Will hold an overload which is five times greater than the ampere rating of the fuse for a minimum of ten seconds. 250 V maximum. UL listed, CSA Certified.

• Bussmann Series fusetron cartridge fuses are 23% more energy efficient and offer the best time-delay performance
• Their dual element feature allows closer sizing to load for great protection of motors and transformers
• When sized correctly, they help protect motors from burnout caused by overloads or single-phasing
• The time-delay feature allows the initial startup current surge for typical motors to pass, but opens prior to motor burnout when longer, dangerous overloads are present

Voltage Rating250 VAC, 125 VDCCurrent Rating25Interrupt Rating20, 200Fuse TypeLow Voltage, Time DelayFuse GroupHElement TypeDualIndicator TypeNon-IndicatingRejection/Non-RejectionRejectionTerminal TypeHolderBody MaterialFiberglassDiameter9/16Length2
