PSCA 1/2 Panel Sheathing Clip, 20 ga Thick Material, Steel, Zinc Galvanized – Simpson Strong-Tie

Description

The PSCA is designed to brace unsupported sheathing edges when sheathing meets edge to edge without a rafter for support. This light sheathing clip provides a 1/8 in gap to address shrinkage and expansion of roof sheathing. Inserted over the edges of adjacent plywood panels, the PSCA reduces deflection and keeps panels even to maintain a level plane on the structure.

• Quick-installation, no nails required
• Provides a secure environment for sheathing
• Support for shrinkage and expansion over time
• Provides the 1/8 in space between plywood panels as recommended by the American Plywood Association
• Use the same size sheathing clip as the panel thickness
• For panel thickness of 1/2 in
• Made from 20 ga steel
• Galvanized (G90) for corrosion-resistance

MaterialSteelFinishZinc GalvanizedMaterial Thickness20Maximum Roof Span32 with Clip, 28 without ClipNumber of PC per Spans1
