Description
Eaton Cooper Wiring TRUSBAC20 Duplex Receptacle, 125 VAC, 5 A, Frequency Rating: 130 kHz, Number of Poles: 2, Number of Wires: 3, Number of USB Ports: 2, USB Type: Type A, C, Wiring Type: Back, Side, Wire Size: 10 to 14 AWG, NEMA Configuration: NEMA 5-20R, Operating Temperature: -4 to 140 deg F, Strap Mounting, Thermoplastic/Steel, Ivory, Dimensions: 4.19 in H x 1.3 in W x 1.67 in D
- Standard AC receptacle with USB and USB-C ports rated at a combined 5.0A
- USB-C charging port charges most electronic devices that comply with the USB-C standard
- Tamper-resistant shutters provide compliance with 2017 NEC® Article 406.12 that states that all 15 A and 20 A, 125 V receptacles installed in dwelling units must be tamper-resistant
- Replaces a standard duplex receptacle
- Automatic grounding system eliminates need for bonding jumper in grounded metal enclosure, provides redundant measure of ground continuity where jumper is used
- Thermoplastic top and back body are virtually unbreakable to deliver years of durable performance
- Steel mounting strap is zinc-plated for added corrosion resistance
Voltage Rating125Current Rating5Frequency Rating130Number of Poles2Number of Wires3Number of USB Ports2USB TypeType A/CWiring TypeBack, SideWire Size10 to 14NEMA ConfigurationNEMA 5-20ROperating Temperature-4 to 140Mounting TypeStrapMaterialThermoplastic/SteelColorIvoryDimensions4.19 in H x 1.3 in W x 1.67 in D
